NZXT H510 ATX Mid Tower Chassis Tempered Glass (Black)

Our best-selling case is loved by more than 100,000 customers!

This compact mid-tower is an ideal case for the majority of builds. The H510 is easy-to-build-in and offers flexibility for a variety of ATX parts.

  • Iconic cable management bar and uninterrupted tempered-glass side panel
  • USB 3.2 Gen2-compatible USB-C connector on the front panel
  • Cable routing kit with pre-installed channels and straps
  • Two Aer F120mm fans and removable filter on PSU intake
  • Removable bracket designed for radiators up to 280mm
₱3,800.00
Tax included. Shipping calculated at checkout.
Add to WishlistCompare
NZXT
Vendor: NZXT
Type: PC Case
SKU: CASE-NZXT H510 BLK/BLK TG ATX
Availability : In Stock Pre order Out of stock
Categories: All regular products PC Cases PC Components
Tags: (Black/Black) (CA-H510B-B1) ATX H510 Mid Tower Chassis NZXT TEMPERED GLASS
Description

SPECIFICATION

KEY SPECS

Motherboard Support

Mini-ITX, MicroATX, ATX

Enclosure Type

Compact Mid-Tower

Case Material

SGCC Steel, Clear Tempered Glass

DIMENSIONS

Height

460mm / 18.11 inches

Width

210mm / 8.27 inches

Depth

428mm / 16.85 inches

Weight

6.6 kg / 14.55 lb

COMPATIBILITY & CLEARANCE

Max CPU Cooler Clearance

165mm

Max GPU Clearance

381mm

Front Fan & Radiator Clearance

60mm

Cable Management

19 - 23mm

FRONT I/O PORTS

USB 3.2 Gen 1 Type-A

1

USB 3.2 Gen 2 Type-C

1

Headset Audio Jack

1

EXPANSION SLOTS

Standard

7

Vertical

-

DRIVE BAYS

2.5"

2 + 1

3.5"

2 + 1

FAN SUPPORT

Front

2 x 120mm / 2 x 140mm

Top

1 x 120mm / 1 x 140mm

Rear

1 x 120mm

Filters

All air intakes

RADIATOR SUPPORT

Front

280mm

Top

-

Rear

120mm

FAN SPECS

Model

Aer P 120mm (Case Version)

Speed

1,200 ± 200RPM

Airflow

50.42 CFM

Noise

28 dBA

Fan Connector

3-pin

GENERAL

Model Number

CA-H510B-W1

UPC

815671014764

EAN

5060301695065
