Features
Low Latency Gaming Mode
Improved communication time from the input source to your projector allows for an enhanced gaming experience.
USB-A Power for Devices
Power your external devices like Amazon Firestick or Roku with the convenient USB-A input right on the projector.
Industry-leading Lamp Life
The Genesis Series features up to an unprecedented 15,000 hours of lamp life when used in Dynamic Mode. With no filters to replace, these projectors are an unbeatable value.
High Brightness
Get better, brighter images on any surface, in any light. The Genesis Series has up to 3800 lumens.
Advanced Digital Image Correction
With the new digital edge masking and image shift features – we make getting those final image adjustments perfect.
Zoom
The zoom ratio adds flexibility for installations using pre-existing mounts. Adjust the zoom to create the perfect image in the same space.
SPECIFICATION
| Image | |
| Projection Technology | Texas Instruments DLP® |
| Panel Size | 0.55" DMD |
| Native Resolution | XGA |
| Pixels | 1024 x 768 |
| Aspect Ratio | 4:3 |
| Contrast Ratio | 30000:1 |
| Brightness (Lumens) | 3800 |
| Light Source | UHP Lamp |
| Light Source Life Maximum Hours | 15000 |
| Maximum Supported Resolution | 1920 x 1200 |
| Horizontal Sync. Range (KHz) | 31 ~ 97 |
| Vertical Sync. Range (Hz) | 56 ~ 85 |
| Uniformity (%) | 80 |
| Optical | |
| Lens | 1.1x |
| Lens Zoom Adjustment | Manual |
| Optional Lenses | - |
| Image Offset (%) | 115 |
| Focal Length (mm) | 21.85 ~ 24.01 |
| F-Stop | 2.41 |
| Vertical Lens shift (%) | - |
| Horizontal Lens shift (%) | - |
| Keystone Adjustment | Manual |
| Vertical Keystone Correction | ± 40° |
| Horizontal Keystone Correction | - |
| Projection Factor | 1.94:1 ~ 2.16:1 |
| Projection Distance (Meters/Feet) | 1.2 ~ 11.9 / 3.9 ~ 39 |
| Optical Zoom | 1.1:1 |
| Digital Zoom Demagnification / Magnification | 0.8x ~ 2.0x |
| Focus Adjustment | Manual |
| Connectivity | |
| Inputs | |
| Mini D-sub 15-pin (VGA) | ✅ |
| Composite Video | - |
| S-Video | ✅ |
| HDMI™ 1.4 | ✅ |
| HDMI™ 2.0 | - |
| USB-B 2.0 | - |
| RJ45 - LAN 10/100/1000 | - |
| 3.5 mm Stereo Mini Jack | ✅ |
| 3.5 mm Stereo Mini Jack with Microphone | - |
| Outputs | |
| Mini D-sub 15-pin (VGA) | - |
| 3.5 mm Stereo Mini Jack | ✅ |
| Powered USB-A for Wireless Dongle | ✅ |
| 3D Sync | - |
| Other | |
| RS232 | - |
| RJ45 HDBaseT | - |
| All Major 3D Formats | ✅ |
| USB-B 2.0 for Service | - |
| USB-A for Service | ✅ |
| Micro USB for Service | - |
| Document Reader | - |
| Video Player | - |
| Photo Viewer | - |
| Music Player | - |
| 12v Screen Trigger | - |
| Power | |
| Power Supply | 100 ~ 240 V AC; 50 ~ 60 Hz |
| Power Consumption Max (W) | 267 |
| Power Consumption Min. (W) | 210 |
| Power Consumption Network Standby (W) | - |
| Power Consumption Standby (W) | <0.5 |
| General | |
| Dimensions (W x H x D) (mm / in) | 236 x 313 x 107 / 9.3 x 12.4 x 4 |
| Product Weight (Kilograms/Pounds) | 2.6 / 5.7 |
| Fan Noise (dB) | 30 |
| Audio (W) | 3 |
| Operating Temperature (Celsius/Fahrenheit) | 5 ~ 40 / 41 ~ 104 |
| Operating Humidity (%) | 10 ~ 85 |
| Max Operating Altitude (meters / feet) | 3048 / 10000 |
| Storage Temperature (Celsius/Fahrenheit) | -10 ~ 60 / 14 ~ 140 |
| Storage Humidity (%) | 10 ~ 85 |
| Security | Kensington Security Slot™, PIN Code Lock & Timer |
| Safety and Regulatory | CB, CE, EAC, cTUVus, CCC, FCC, UKCA, NOM, PSB, BIS |
| Environmental | WEEE, EU RoHS, China RoHS, CEL, CECP |
