Motherboard Support |
EATX (12"x10.9"), ATX, Micro-ATX, Mini-ITX |
|
Drive Bays |
5 x 2.5" Bay, 2 x 2.5"/3.5" Combo Bay |
|
Expansion Slots |
9 (3 additional vertical) |
|
Front I/O Port |
1 x headphone/microphone, 4 x USB 3.2Gen1, 1 x USB 3.2 Gen2 Type C, LED Control Button, Reset Button, 1 x USB 4.0 Type C or 1 x USB 3.2 Gen 2x2 Type C (spec may vary by region) |
|
Tempered Glass |
Left Side, Right Side |
|
Radiator Support (Front) |
120mm, 140mm, 240mm, 280mm, 360mm, 420mm |
|
Radiator Support (Top) |
120mm, 140mm, 240mm, 280mm, 360mm, 420mm |
|
Radiator Support (Rear) |
120mm, 140mm |
|
Cooling Support (Front) |
3 x 120mm, 3 x 140mm |
|
Cooling Support (Top) |
3 x 120mm, 3 x 140mm |
|
Cooling Support (Rear) |
1 x 120mm, 1 x 140mm |
|
Pre-installed Fans (Front) |
3 x 140mm PWM |
|
Pre-installed Fans (Rear) |
1 x 140mm PWM |
|
Maximum CPU Cooler Height |
190mm |
|
Maximum GPU Length |
460mm |
|
Maximum PSU Length |
240mm |
|
Removable Dust Filters |
Front, Top, Bottom |
|
Maximum Cable Management Space |
34mm |
|
Dimensions |
268mm x 639mm x 659mm |
|
Weight |
20.8 Kg (21.3 Kg for GR701 BTF Edition) |
