Scanner Type |
ADF (Automatic Document Feeder) / Manual Feed, Duplex |
|
Scanning Speed (A4) |
Auto mode: Simplex / Duplex: 40 ppm |
|
Normal mode: Simplex / Duplex: 40 ppm (Color / Grayscale: 150 dpi, Monochrome: 300 dpi) |
|
|
Better mode: Simplex / Duplex: 40 ppm (Color / Grayscale: 200 dpi, Monochrome: 400 dpi) |
|
|
Best mode: Simplex / Duplex: 40 ppm (Color / Grayscale: 300 dpi, Monochrome: 600 dpi) |
|
|
Excellent mode: Simplex / Duplex: 10 ppm (Color / Grayscale: 600 dpi, Monochrome: 1,200 dpi) |
|
|
Scanning Color Mode |
Color, Grayscale, Monochrome, Automatic (Color / Grayscale / Monochrome detection) |
|
Image Sensor |
CIS x 2 (Front x 1, Back x 1) |
|
Light Source |
3 color LED (Red / Green / Blue) |
|
Optical Resolution |
600 dpi |
|
Document Size |
Normal Scan: Minimum 50.8 x 50.8 mm (2 x 2 in.), Maximum 216 x 360 mm (8.5 x 14.17 in.) |
|
Manual Scan: A3, B4, 279 x 432 mm (11 x 17 in.) |
|
|
Long Paper Scanning |
3,000 mm (863 mm in 32-bit), Smart Device: 863 mm (Duplex), 1,726 mm (Simplex) |
|
Paper Weight |
40 to 209 g/m2 (11 to 56 lb), A8 or less: 128 to 209 g/m2 (34 to 56 lb) |
|
Cards: 0.76 mm or less (Compliant with the ISO7810 ID-1 type) (Includes embossed cards) |
|
|
ADF Capacity |
50 sheets (A4, 80 g/m2 or 20 lb) |
|
Multifeed Detection |
Overlap detection (Ultrasonic sensor), Length detection |
|
Interface |
USB: USB3.2 Gen1x1 / USB2.0 / USB1.1 (Connector Type: Type-B) |
|
Wi-Fi |
IEEE802.11a/b/g/n/ac, Frequency band: 2.4 GHz / 5 GHz |
|
Wi-Fi Interface |
Connection Mode: Access Point Connect Mode (Infrastructure mode), Direct Connect Mode (Ad-hoc mode) |
|
Security |
WEP (64bit / 128bit), WPA (TKIP / AES), WPA2 (AES), WPA-PSK (TKIP / AES), WPA2-PSK (AES) |
|
Easy Installation |
WPS2.0 |
|
Rated Power (EIRP) |
2.4 GHz: 11b: +19.0dBm / 11g: +20.5dBm / 11n/ac: +20.5dBm (20 / 40MHz), 5 GHz: 11a: +15.5dBm / 11n/ac: +16.5dBm (20MHz) |
|
LCD |
4.3 in. color TFT touch screen |
|
Power Requirements |
AC 100 to 240 V, 50/60 Hz |
|
Power Consumption |
Operating Mode: 17 W or less |
|
Sleep Mode: USB connected: 1.5 W or less, Wi-Fi connected: 1.6 W or less |
|
|
Operating Environment |
Temperature: 5 to 35 °C (41 to 95 °F) |
|
Relative Humidity |
20 to 80% (Non-condensing) |
|
Environmental Compliance |
ENERGY STAR®, RoHS |
|
Dimensions (W x D x H) |
292 x 161 x 152 mm (11.5 x 6.3 x 6.0 in.) |
|
Weight |
3.4 kg (7.5 lb) |
|
Driver |
ScanSnap specific driver |
|
Software |
ScanSnap Home (All-in-one document management software/driver) |
