UBIQUITI UNVR (Network Video Recorder)
- Read our FAQs before ordering
- Need Help? Chat with us.
Product

Deployment

Build Feature

SPECIFICATION
Mechanical |
|
Dimensions |
442 x 325 x 44 mm (17.4 x 12.8 x 1.7") |
Weight |
Without mounting brackets: 5.1 kg (11.3 lb) |
Enclosure Material |
SGCC steel |
Mount Material |
SGCC steel |
Hardware |
|
Management Interface |
Ethernet In-Band |
Networking Interface |
(1) GbE RJ45 port |
Power Method |
(1) Universal AC input, 100–240V AC, 2A Max., 50/60 Hz |
Power Supply |
AC/DC, internal, 120W |
Supported Voltage Range |
100–240V AC |
Max. Power Consumption |
100W |
Max. Power Budget for Drives |
75W |
ESD/EMP Protection |
Air: ±12kV |
Environment |
|
Ambient Operating Temp. |
-5 to 40° C (23 to 104° F) |
Ambient Operating Humidity |
5 to 95% noncondensing |
Certifications |
FCC, CE, IC |
Capacity |
|
HD Cameras |
60 |
2K Cameras |
30 |
4K Cameras |
18 |
LEDs |
|
System |
Power: blue/white |
Ethernet |
Green: 1 Gbps |
SFP+ |
White: 10 Gbps |
HDD |
White: disk detected |
RPS |
Blue: ready |
