TP-LINK Tapo C545D Outdoor Dual Lens Pan/Tilt Security Wi-fi Camera
- Read our FAQs before ordering
- Need Help / Out of Stock? Chat with us.
SPECIFICATION
|
Image Sensor |
1/2.8″ Progressive-Scan CMOS |
|
Lenses |
Two lenses: |
|
Field of View (FOV) |
Wide-angle: 165.1° (diagonal), 137.6° (horizontal), 73.0° (vertical) |
|
Resolution |
Dual 2K (3MP) for both lenses: 2304 × 1296 px |
|
Frame Rate |
15 fps |
|
Video Compression |
H.264 |
|
Night Vision |
<ul><li>850 nm IR LED, up to ~29.9 m (99 ft)</li><li>Color Night Vision</li></ul> |
|
Day/Night Switch |
IR-Cut filter with auto-switching |
|
Pan / Tilt |
<ul><li>Wide-angle (top) lens — manual pan: 270°, tilt: –30° to –10° </li><li>Telephoto (bottom) lens — automatic pan & tilt for tracking motion </li></ul> |
|
Zoom |
Telephoto lens supports up to 10.8× digital zoom |
|
Audio |
Built-in microphone and speaker; two-way audio with noise cancellation |
|
Siren |
99 dB (measured at ~10 cm) |
|
Storage |
microSD slot up to 512 GB |
|
AI / Detection |
Motion detection, person detection, pet detection, vehicle detection, line-crossing detection, camera tampering; custom activity zones |
|
Network |
<ul><li>Wi-Fi: IEEE 802.11 b/g/n/ax (2.4 GHz)</li><li>Ethernet: 1× RJ45 10/100 Mbps</li><li>Supports: RTSP, ONVIF </li></ul> |
|
Security |
128-bit AES encryption with SSL/TLS, WPA/WPA2-PSK/WPA3, on-device machine learning |
|
Power |
12 V DC adapter; 100-240 V input, 1 A output; typical power ~5.3 W, max ~11.2 W |
|
Weather Resistance |
IP66 rating (dust & water resistant) |
|
Operating Temperature |
–30 °C to +60 °C (–22 °F to 140 °F) |
|
Storage Temperature |
–40 °C to +60 °C (–40 °F to 140 °F) |
|
Humidity (Operating) |
10%–90% RH, non-condensing |
|
Dimensions |
114.57 mm (W) × 159.55 mm (D) × 152.1 mm (H) |
|
Weight |
~491 g (17.32 oz) |
|
Mounting Options |
Wall, ceiling, or pole mount supported |
|
Smart Integration |
Google Assistant, Amazon Alexa, Samsung SmartThings |
