WIRELESS
|
|
|
Standards
|
Wi-Fi 6
IEEE 802.11ax/ac/n/a 5 GHz
IEEE 802.11ax/n/b/g 2.4 GHz
|
|
WiFi Speeds
|
AX3000
5 GHz: 2402 Mbps (802.11ax, HE160)
2.4 GHz: 574 Mbps (802.11ax)
|
|
WiFi Range
|
2-3 Bedroom Houses
4× Fixed High-Performance Antennas
Multiple antennas form a signal-boosting array to cover more directions and large areas
Beamforming
Concentrates wireless signal strength towards clients to expand WiFi range
High-Power FEM
Improves transmission power to strengthen signal coverage
|
|
WiFi Capacity
|
High
Dual-Band
Allocate devices to different bands for optimal performance
OFDMA
Simultaneously communicates with multiple Wi-Fi 6 clients
Airtime Fairness
Improves network efficiency by limiting excessive occupation
DFS
Access an extra band to reduce congestion
4 Streams
Connect your devices to more bandwidth
|
|
Working Modes
|
Router Mode
Access Point Mode
|
|
HARDWARE
|
|
|
Processor
|
Dual-Core CPU
|
|
Ethernet Ports
|
1× Gigabit WAN Port
4× Gigabit LAN Ports
|
|
Buttons
|
Wi-Fi/WPS Button
Power On/Off Button
Reset Button
|
|
Power
|
12 V ⎓ 2 A
|
|
SECURITY
|
|
|
WiFi Encryption
|
WPA
WPA2
WPA3
WPA/WPA2-Enterprise
|
|
Network Security
|
SPI Firewall
Access Control
IP & MAC Binding
Application Layer Gateway
HomeShield Security
Real-Time IoT Protection
Malicious Site Blocker
Intrusion Prevention System
DDoS Attack Prevention
Home Network Scanner
|
|
Guest Network
|
1× 5 GHz Guest Network
1× 2.4 GHz Guest Network
|
|
VPN Server
|
OpenVPN
PPTP VPN
|
|
SOFTWARE
|
|
|
Protocols
|
IPv4
IPv6
|
|
Service Kits
|
HomeShield
|
|
OneMesh™
|
OneMesh™ Supported
Without replacing your existing devices or buying a whole new WiFi ecosystem, OneMesh™ helps you create a more flexible network that covers your entire home with TP-Link OneMesh™ products.
|
|
EasyMesh
|
Mesh networking creates smooth, fast, stable roaming. Archer AX53 can flexibly build an EasyMesh network with EasyMesh-Compatible devices, which eliminates Wi-Fi dead zones, expand your network, and fill your entire home with high-speed Wi-Fi. Seamless Wi-Fi connections with one network name, one-click setting and flexible scalability.
|
|
Parental Controls
|
HomeShield Parental Controls
Custom Profiles
Professional Content Filter Library
Family Time
Bedtime
Off Time
Time Rewards
Family Online Time Ranking
Pause the Internet
Weekly and Monthly Reports
|
|
WAN Types
|
Dynamic IP
Static IP
PPPoE
PPTP
L2TP
|
|
Quality of Service
|
QoS by Device
|
|
Cloud Service
|
Auto Firmware Upgrade
OTA Firmware Upgrade
TP-Link ID
DDNS
|
|
NAT Forwarding
|
Port Forwarding
Port Triggering
DMZ
UPnP
|
|
IPTV
|
IGMP Proxy
IGMP Snooping
Bridge
Tag VLAN
|
|
DHCP
|
Address Reservation
DHCP Client List
Server
|
|
DDNS
|
TP-Link
NO-IP
DynDNS
|
|
Management
|
Tether App
Webpage
|
|
OTHER
|
|
|
System Requirements
|
Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
Cable or DSL Modem (if needed)
Subscription with an internet service provider (for internet access)
|
|
Certifications
|
CE, RoHS
|
|
Environment
|
Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Operating Humidity: 10%~90% non-condensing
|
|
TEST DATA
|
|
|
WiFi Transmission Power
|
CE:
<20dBm (2.4GHz); <23dBm (5.15GHz~5.35GHz); <30dBm (5.47GHz~5.725GHz)
|
|
WiFi Reception Sensitivity
|
2.4GHz:
11ac VHT20_MCS0:-96dBm
11ac VHT20_MCS8:-74dB
11ac VHT40_MCS0:-94dBm
11ac VHT40_MCS9:-70dB
11ax HE20_MCS0:-96dBm
11ax HE20_MCS11:-66dBm
11ax HE40_MCS0:-93dBm
11ax HE40_MCS11:-63dBm
5GHz:
11ac VHT20_MCS0:-97dBm
11ac VHT20_MCS8:-75dBm
11ac VHT40_MCS0:-94dBm
11ac VHT40_MCS9:-70dBm
11ac VHT80_MCS0:-91dBm
11ac VHT80_MCS9:-67dBm
11ac VHT160_MCS0:-88dBm
11ac VHT160_MCS9:-63dBm
11ax HE20_MCS0:-97dBm
11ax HE20_MCS11:-66dBm
11ax HE40_MCS0:-94dBm
11ax HE40_MCS11:-63dBm
11ax HE80_MCS0:-91dBm
11ax HE80_MCS11:-61dBm
11ax HE160_MCS0:-87dBm
11ax HE160_MCS11:-58dBm
|
|
PHYSICAL
|
|
|
Dimensions (W×D×H)
|
10.2 × 5.3 × 1.6 in
(260.2 × 135 × 41.6 mm)
|
