LENOVO 23.8" R24E LEGION (67CCGAC4PH) IPS Monitor
- Read our FAQs before ordering
- Need Help? Chat with us.
SPECIFICATION
Display Size |
23.8″ |
View Area |
527 × 296.5 mm |
Panel |
In‑Plane Switching (IPS) |
Backlight |
WLED |
Aspect Ratio |
16 : 9 |
Resolution |
1920 × 1080 |
Pixel Pitch |
0.2745 × 0.2745 mm |
Dot / Pixel Density |
93 dpi |
Viewing Angle (H / V) |
178° / 178° |
Response Time |
0.5 ms (MPRT) / 1 ms (Level 4) / 2 ms (Level 3) / 3 ms (Level 2) / 4 ms (Level 1) |
Color Support |
16.7 million |
Refresh Rate |
48 Hz – 180 Hz |
Brightness |
300 cd/m² |
Contrast Ratio |
1000 : 1 |
Native Contrast Ratio |
— |
Color Gamut |
99 % sRGB |
Screen Surface Treatment |
Anti‑glare |
Curvature |
None |
Camera |
None |
Microphone |
None |
Speakers |
None |
Power Consumption (Typical / Maximum) |
16.6 W / 24 W |
Power Adapter |
Integrated |
Touchscreen |
None |
Smart System |
None |
Stand |
Tilt, Swivel, Pivot, Height‑adjustable stand |
Case Color |
Raven Black |
Side Bezel Width |
2.6 mm |
Mounting |
VESA 100 × 100 mm |
ThinkCentre M Series Support |
None |
Pen |
None |
Dimensions – Lowest Position (W × D × H) |
540.4 × 258.6 × 388.0 mm (21.28 × 10.18 × 15.28 in) |
Dimensions – Highest Position (W × D × H) |
540.4 × 258.6 × 523.0 mm (21.28 × 10.18 × 20.59 in) |
Dimensions – Head Only (W × D × H) |
540.4 × 51.7 × 325.3 mm (21.28 × 2.04 × 12.81 in) |
Packaging Dimensions (W × D × H) |
642.0 × 187.0 × 462.0 mm (25.28 × 7.36 × 18.19 in) |
Weight – With Stand |
4.8 kg (10.6 lbs) |
Weight – Head Only |
2.9 kg (6.4 lbs) |
Packaging Weight |
7.0 kg (15.4 lbs) |
USB Port |
None |
Video Connector |
1 × HDMI® 2.1 (TMDS); 1 × DP 1.4 (HBR2) |
Environmental Certification |
RoHS; EU Energy Efficiency Level E |
Ergonomic Certification |
TÜV Rheinland® Eye Comfort 2.0 |
Sync Technology |
AMD FreeSync™ Premium |
Special Features |
AMD FreeSync™; Lenovo® Artery support; gaming‑console compatible |
Operating System Compatibility |
Windows 10, Windows 11 |
Accessories |
HDMI® cable |
Model |
67CCGAC4PH |
