Interfaces |
5 x 1000Base-T |
|
Auto MDI/MDIX |
Yes |
|
Switching Capacity |
10 Gbps |
|
Max. Packet Forwarding Rate |
7.44 Mpps |
|
Store & Forwarding Forwarding |
Yes |
|
Dimensions |
91 x 73 x 22 mm |
|
Weight |
800 g |
|
Operating Temperature |
0 ~ 40 °C |
|
Storage Temperature |
-10 ~ 70 °C |
|
Storage Humidity |
0% ~ 95% RH |
|
Operating Humidity |
0% ~ 95% RH |
|
Operating Altitude |
2000 m |
|
Maximum Power Consumption |
3.90 W |
|
Air Discharge |
8 kV |
|
Surge/Lightning Protection |
AC Power Inet: 1 kV |
|
Jumbo Frame |
9,720 Bytes |
|
Head-of-line (HOL) Blocking Prevention |
Yes |
|
Control |
802.3x Flow |
|
MAC Address Table Size |
4,000 |
|
Power Saving By Cable Length |
Yes |
|
Power Saving By Link Status |
YES |
|
Energy Efficiency Ethernet (EEE) |
Yes |
|
Comply with RoHS 6 |
Yes |
|
FAN |
Fanless |
|
Packet Buffer Size |
128 KBytes |
|
Flash Memory Size |
64 KBytes |
|
Power Input |
AC: 100 ~ 240 V |
|
MTBF |
1,152,221 hours |
|
Maximum Heat Dissipation |
13.299 BTU/h |
|
Standby Power Consumption |
0.6 W |
