Dimensions |
406 × 206 × 450 mm (D × W × H) |
|
Form Factor |
Mid Tower |
|
Materials |
Steel + Plastic |
|
Mainboard Support |
E-ATX, ATX, Micro-ATX, ITX |
|
Front Access & Controls |
Power, Reset, USB 2.0 ×2, USB 3.0 ×1, Headphone/Mic Combo Jack |
|
Side Panel |
Tempered glass |
|
Expansion Slots |
7 |
|
3.5" / 2.5" Bays |
2 / 1 |
|
2.5" Bays |
2 |
|
Front Fan Support |
3 × 120 mm / 2 × 140 mm |
|
Top Fan Support |
2 × 120 mm / 2 × 140 mm |
|
Power Supply Shroud Fan Support |
2 × 120 mm |
|
Rear Fan Support |
1 × 120 mm |
|
Included Fans (NX292 White) |
3 × 120 mm fixed-mode RGB (front) + 1 × 120 mm regular fan (rear) |
|
Included Fans (NX292 Elite White) |
3 × 120 mm RGB fixed-mode (front) + 1 × 120 mm RGB fixed-mode (rear) |
|
Front Radiator Support |
120 / 140 / 240 / 280 / 360 mm |
|
Rear Radiator Support |
120 mm (Length ≤ 156 mm) |
|
Max GPU Length |
≤ 320 mm |
|
Max CPU Cooler Height |
≤ 155 mm |
|
Max PSU Length |
≤ 165 mm (with HDD) / ≤ 300 mm (without HDD) |
|
Dust Filters |
Top / Bottom |
|
Net Weight |
4.5 kg (NX292 White) / 4.94 kg (NX292 Elite White) |
|
Gross Weight |
5.3 kg (NX292 White) / 5.91 kg (NX292 Elite White) |
|
UPC |
0-761345-81039-5 (NX292 Elite White) |
