Centrally store photos, music, and videos; easily browse, organize, and share multimedia files.
With a built-in NPU (Neural network Processing Unit) processor, the TS-433 boosts performance for high-speed face and object recognition.
Supports ARM NEON technology that accelerates video processing for a greater entertainment experience.
myQNAPcloud allows you to easily access, manage, and share NAS files via the Internet.
Protect your files and data from accidental deletion and malware attacks by using advanced snapshot protection.
Serves as a secure private cloud and supports user account protection, IP blocking, 2-step verification, encryption access, and more.
|
TS-CPU |
ARM 4-core Cortex-A55 2.0GHz processor |
|
CPU Architecture |
64-bit ARM |
|
Graphics Processor |
Mali-G52 |
|
System Memory |
4 GB on board (non-expandable) |
|
Maximum Memory |
4 GB on board (non-expandable) |
|
Flash Memory |
4 GB (Dual boot OS protection) |
|
Drive Bay |
4 x 3.5-inch SATA 6Gb/s, 3Gb/s |
|
Drive Compatibility |
- 3.5-inch SATA hard disk drives |
|
Hot-swappable |
Yes |
|
Ethernet Ports |
- 1 x Gigabit Ethernet (RJ45) |
|
Wake on LAN (WOL) |
Not specified |
|
Jumbo Frame |
Not specified |
|
USB Ports |
2 x USB 2.0 |
|
Form Factor |
Tower |
|
LED Indicators |
System Status, LAN, USB, HDD1~4 |
|
Buttons |
Power, Reset, USB Copy |
|
Dimensions (HxWxD) |
165 × 160.2 × 220.5 mm |
|
Weight |
Net: 2.07 kg |
|
Operating Temperature |
0 - 40 °C (32°F - 104°F) |
|
Storage Temperature |
-20 - 70 °C (-4°F - 158°F) |
|
Relative Humidity |
5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
|
Power Supply Unit |
Minimum 65W adapter (12VDC), 100-240VAC |
|
Power Consumption |
- Disk Standby Mode: 8.45W |
|
Fan |
1 x 120mm, 12VDC |
|
System Warning |
Buzzer |
|
Kensington Security Slot |
Present |
|
Max. Concurrent Connections (CIFS) |
200 |
